شرکت فناوری قدرت جهانی وو شی، با مسئولیت محدود
کاربر اول، صداقت محور؛ ایجاد برند GP با کیفیت، کسب اعتبار با خدمات.
جزئیات محصول:
پرداخت:
|
| نوع خروجی: | AC سه فاز | ولتاژ نامی:: | 220/380 ولت |
|---|---|---|---|
| توان اولیه (کیلووات بر کیلووات): | 45/56 | توان آماده به کار (kw/kva): | 50/62 |
| مدل موتور: | Isuzu 4BD1-Z1/53 را کپی کنید | قدرت موتور: | 53 کیلووات |
| فرکانس: | 60 هرتز | وزن: | 1000 کیلوگرم |
| نام تجاری آلترناتور: | Stamford, Mecc-alte, Faraday, stamford را کپی کنید | بسته: | کیس فوم یا تخته سه لا پلاستیکی |
| برند ماژول کنترل: | دپسي، کاماپ، اسمارتجن | ||
| برجسته کردن: | ,,brushless alternator generator |
||
Guarantee
1) Guarantee Period: One year or 1000 running hours whichever comes first.
2) During the guarantee period, the spare-parts will be sent through your shipping agency in China.
3) Spare-parts can also be sent by air express.
4) 24 hours service hotline is available for customers.
Our Service:
1. If you are interested in our products we sincerely invite you to take a visit of our factory when you are in China. We can drive to pick you up and visit our factory.
2. Suggest the best choice or referential suggestion based on customers’ information. Answer all questions about the product from customer.
3. Build customers’ profiles, follow-up service, make regular calls on customers.
Our Features :
1) Universal design and manufacture
2) Engineers are familiar with diesel generators powered by Cummins engine
3) You could find spare-parts easily.
4) Automatic voltage regulator protects your sensitive electronics from harmonic distortion and unstable power quality
5) Soundproof type: Very quite running–75dB(A)at 23ft(7m) at normal load.
6) Enclosed muffler for added quietness
7) Service and maintenance accessible through easy-latch side service door
Control system
Brand: DeepSea,Comap,Smartgen
feature:
Our Factory :
Technical Specifications:
| Genset | Voltage Recovery Time | ≤1S | |
| Rated Frequency (Hz) | 50 | ||
| Frequency Recovery Time | ≤5S | ||
| Running Noise db(A)/7m(Silent type) | 75 | ||
| Battery capacity (V-Ah) | 12V 100Ah | ||
| Open Type-Dimension (L*W*H) (mm) | 1770*750*1130 | ||
| Open Type-Weight (kg) | 700 | ||
| Soundproof Type- Dimension (L*W*H) (mm) | 2500*1000*1300 | ||
| Soundproof Type-Weight (kg) | 1120 | ||
| Fuel Tank Capacity(L) | 120 | ||
| Engine | Cylinder No. & Config. | 4, in-line | |
| Combustion System | direct injection | ||
| Compression Ratio | 16.5:1 | ||
| Displacement (L) | 3.9 | ||
| Bore X Stroke (mm) | 102*120 | ||
| Engine Speed (r/min) | 1500 | ||
| Speed Governing | Mechanical | ||
| Starting System | 24V DC Electric | ||
| Filter System | Dry oil filter/Fuel filter/Oil filter | ||
| Cooling system | Water-cooled | ||
| Alternator | Alternator brand | Stamford, Mecc-alte,Faraday… | |
| Excitation System | Brushless, self-exciting | ||
| Voltage Regulation Mode | AVR | ||
| Connection Type | 3phase,4wires,”Y” connection | ||
| Pole No. | 4 | ||
| Rotation Speed (r/min) | 1500 | ||
| Temperature Rise (℃) | 125 | ||
| Insulation class | H | ||
| Voltage Regulation (0 load) | ≥95%～105% | ||
| Protection Grade |
IP23 |
||
