شرکت فناوری قدرت جهانی وو شی، با مسئولیت محدود
کاربر اول، صداقت محور؛ ایجاد برند GP با کیفیت، کسب اعتبار با خدمات.
جزئیات محصول:
پرداخت:
|
| نرخ تحویل هوایی: | 1.6 متر مکعب در دقیقه | فشار کاری: | 30 نوار |
|---|---|---|---|
| تایپ کنید: | درایو رفت و برگشتی پیستون | حالت: | روغن کاری موتور الکتریکی AC |
| سبک: | روغن کاری شده | وزن: | 600 کیلوگرم |
| بازار: | جهانی | کد Hs: | 8414809090 |
| برجسته کردن: | portable air compressor,quiet air compressor,quiet air compressor |
||
Model Specification:
3Mpa piston air compressor
| Block type | PISTON | PISTON | PISTON | PISTON | PISTON | PISTON | PISTON |
| Volume(m3/min) | 0.6 | 0.8 | 1.0 | 1.2 | 1.6 | 2.0 | 3.0 |
| W.Pressure(Mpa) | 3.0 | 3.0 | 3.0 | 3.0 | 3.0 | 3.0 | 3.0 |
| RPM(r/min) | 830 | 800 | 780 | 780 | 830 | 830 | 780 |
| Lubrication | splash | splash | splash | splash | splash | splash | splash |
| drive | belt | belt | belt | belt | belt | belt | belt |
| cooling | Air cooling | Air cooling | Air cooling | Air cooling | Air cooling | Air cooling | Air cooling |
| Motor power(Kw) | 7.5 | 7.5 | 11 | 15 | 18.5 | 2X11 | 30 |
| Power source(v/Hz) | 380/50 | 380/50 | 380/50 | 380/50 | 380/50 | 380/50 | 380/50 |
| noise(dB (A)) | ≤72 | ≤72 | ≤78 | ≤78 | ≤85 | ≤85 | ≤85 |
| Cylinders diameter(mm) | 2X¢95 ¢55 |
2X¢100 ¢55 |
2X¢120 ¢65 |
2X¢120 ¢65 |
2X¢135 ¢120 ¢65 |
4X¢120 2X¢55 |
¢210 ¢120 ¢100 |
| size(mm) | 1470(L) 530(W) 1020(H) |
1490(L) 600(W) 1160(H) |
1550(L) 730(W) 1280(H) |
1620(L) 730(W) 1280(H) |
1900(L) 850(W) 1600(H) |
1900(L) 900(W) 1400(H) |
1850(L) 1000(W) 1100(H) |
| weight(Kg) | 290 | 430 | 480 | 520 | 600 | 600 | 1150 |
Our Service:
1. If you are interested in our products we sincerely invite you to take a visit of our factory when you are in China. We can drive to pick you up and visit our factory.
2. Suggest the best choice or referential suggestion based on customers’ information. Answer all questions about the product from customer.
3. Build customers’ profiles, follow-up service, make regular calls on customers.
Company Profile:
Wuxi Global Power Technology Co., Ltd is located in national Hi-tech Nanchang district, Wuxi city, Jiangsu, China, which is famous as the ‘source of power’. Our company is a key-enterprise of being engaged in research, development, manufacture and exportation of energy-saving and environment-friendly generating sets, related parts and supporting equipment.
We mainly produced “Global Power” brand three-phase brushless synchronous alternators and many kinds of diesel generator sets, such as open generator, silent/soundproof generator, outdoor power plant, containerized gensets, trailer gensets and equipments of construction machinery like mobile light tower, forklift, air-compressor and so on.
