شرکت فناوری قدرت جهانی وو شی، با مسئولیت محدود
کاربر اول، صداقت محور؛ ایجاد برند GP با کیفیت، کسب اعتبار با خدمات.
جزئیات محصول:
پرداخت:
|
| موتور: | GP186F/FA | نوع کاربری اراضی واحد: | کم صدا |
|---|---|---|---|
| روش نصب: | ثابت شد | حالت تحریک: | محرک چرخشی AC |
| استفاده: | واحدهای مشترک | روش خنک کننده: | آب خنک کننده |
| نوع خروجی: | AC تک فاز | سیستم عامل دکل: | تک فاز دستی |
| ولتاژ: | 110 ولت، 120 ولت، 220 ولت، 230 ولت، 240 ولت | درجه حفاظت: | IP21-IP23 |
| برجسته کردن: | portable light towers , trailer mounted light towers,trailer mounted light towers |
||
Super Silent Towable Light Tower / Water Cooling Mobile Lighting Tower Hire
1. Manual / Hydraulic heavy-duty winch;
2. Telescopic, mechanical, 3 stages mast up to 9 metres;
3. 360 degree of mast rotation and 180 degree of light bar waving;
4. New unique high pressure aluminum lamps;
5. Separate lockable, weather protected, powder-coated steel doors.
Features of GLOBAL POWER mobile lighting tower:
1. 12months parts Warranty Service
2. Short delivery time, as we always have Japan Kubota & UK engine in stock
3. With ISO9001
4. Spare parts are easy to get from worldwide market with much cheaper price
5. Coupled with Original Stamford alternator, Leory Somer alternator or Copy Stamford alternator
6. Perfect after-service network
7. Both 50Hz and 60Hz
8. Rigorous test including 50% load, 75% load, 100% load and 110% load
Standard Configuration of GLOBAL POWER mobile lighting tower design:
1. Japan Kubota engine, UK engine, Cummins engine, Yangdong engine
2. Original Stamford alternator, faraday, Meccalte alternator or Copy Stamford alternator
3. Weather proof and Soundproof canopy design
4. Control panel : Deepsea, Comap,Smartgen...
5. DELIXI or CHINT circuit breaker
6. 50hours Continuous Working Hours Base Fuel Tank7. Anti-Vibration Mounted System
8. Battery and battery charger
9. Industrial silencer and flexible exhaust hose
10. Big wheels for Road
11. Hydraulic operated mast and Manual operated mast
12. 8M/9M/11M high mast
13. Muilt-options of lamps: 4x1000W, 4x1500W, 4x2000W, 6x1000W, 6x1500W, 6x2000W
Benefits of GLOBAL POWER mobile lighting towers:
1. Stable function, convenient service;
2. Low operating cost results in optional economy;
3. Gets the job done wherever you are;
4. Ease of installation, operation and maintenance.
GLOBAL POWER mobile lighting tower testing items
1) Parts fault testing
2) Fue tank pressure testing
3) Bolt tightening torque testing
4) Painting thickness testing
5) Voltage bearing and insultion testing
6) Noise testing
7) Lamps testing
8) Loading testing: All qualified generator sets are subjected to a comprehensive performance test which inclides 0% load, 25% load, 50% load, 75% load, 100% load and 110% load and to check, verify that all control systems, alarm and shut-own protection
Specification:
| ength(mm) | 2280(1050,Retracted the tow bar & reversed the rear legs) |
| Width(mm) | 1050 |
| Height(mm) | 2760(2270,Deteached a pair of the top lights) |
| Height (Mast be extended fully,mm) | 7060 |
| Weight (Dry,kg) | 460(Without fuel) |
| Engine model | 186FB |
| Frequency (Hz) | 50/60 |
| Speed (rpm) | 3000/3600 |
| Continued Power (kVA) | 2.1/2.3 |
| Number of Cylinders | 1 |
| Diesel Engine Characters | 4 -cycles, air-cooled diesel |
| Combustion Type | Direct injection |
| Engine Aspiration | Naturally aspirated |
| Alternator | Single phase |
| Rating Voltage (V) | 230(AC) |
| Alternator Insulation | Class H |
| Fuel Tank Capacity | 35 liters (10 US Gallons) |
| Operating hours with full fuel | 80 hours |
| Type of lights | LED |
| Number & Power of Lights | 4*300W |
| Number of Mast Sections | 5 |
| Mast Extension | Manually |
| Light Tilt | Manually |
| Stabilizing Legs | Manually |
| Trailer Suspension System | Single torsion axle without brake |
| Hitch & tow bar | The ball or O ring hitch in stable height & "A" tow bar |
| Tire & rim size | 13" |
| Wires & electic components | IP44 |
| Acoustic Pressure | 75dB(A) at 7 meters |
| Max.load quantity in a 20' container(sets) | 10 |
